Laser Welding

laser mould welding machine YAG type mould welding machine

LASER MOULD WELDING MACHINE




Structure: power supply + optical path +pole + worktable + chiller

Product application:

1.Lasermould welding machine AHL-W220IV/AHL-W400IV is the fourth generation oflaser mould repairing equipment developed by AOHUA. This kind of laser can beelectrically operated up and down, left and right or back and forth, and theworktable can be electrically operated up and down, which is mainly applied tooutsize, large and middle-size mould repairing.

2.Mainlyapplicable to mold steel, carbon steel, alloy steel, stainless steel,  beryllium copper, copper alloy, as well assuch plastic mold, casting mold, forging die, stamping mold, die-casting mouldas with extremely hard alloy materials for S136, SKD 每 11, NAK80, 8407, 718,738, H13, P20, W302, 2344.

3.Widelyused in mould manufacturing, such as mobile phone, digital product, automobile,cars, motorcycles, motorcycle mold making and molding industry.


Productadvantages:


1.      Laser mould welding machine fuses thespecial welding wire to the damaged parts of moulds by hi 每 heatinstantaneously generated by laser, and then firmly fuses with the originalsubstrate. After that it conducts the glossy processing through sparks andgrinding in order to repair the mould.

2.      It conducts the precision repair forthe mould*s blisters, cracks, chippings and wearing parts.

3.      The area affected by heat is so smallthat can*t cause the precision mould deformed.

4.       Gasprotecting system: synchronous argon protecting system controlled bymicro-computer act better, it make the welding connection even firmer andartistic. Being controlled to keep synchronous transmission with laser can savethe argon at the highest level.

5.      Laser controlling system can control the power source profile precisely pre 每 set optimized; underthe control of double closed loop by inside improved industrial controllingmicro-computer so the stability and the running ability surpass products thatcontrolled by monolithic integrated circuit.

6.       Observingsystem: equipped with special microscope observing system with cross cursor. Ithas high speed electron flitting device to protect the operator's eyes frombeing hurt.

7.      Fully dissolved and no repairing trace,and there is no depression phenomenon for the joint between convex fuse andsubstrate.


Specification:

Model:

AHL - W220IV

AHL - W400IV

Max.  laser power:

220W

400W

Laser  wavelength:

1064nm

1064nm

Max.  energy per pulse:

90J

110J

Laser  welding depth:

0.1 每 1.0mm

0.1 每 1.6mm

Pulse  width:

0.2 每 20ms

0.2 每 20ms

Continuous  welding frequency:

0.5 每 20HZ

0.5 每 40HZ

Adjustable  facula size:

0.2 每 2mm

0.2 每 2mm

Laser  welding wire:

±0.2 -  ±0.4mm

±0.2  - ±0.8mm

Power  consumption:

≒7KW

≒12KW

Electrical  connection:

220V㊣10%/50HZ/40A

380V㊣10%/50HZ/40A

Standard worktable:

X Y 每  manual, Z - electric

X  Y 每 manual, Z - electric

Positioning:

microscope/CCD  optional

microscope/CCD  optional

Vertical distance of laser:

fixed  300mm

fixed  300mm

Axial rotation of laser:

90

90

Horizontal distance of laser:

X Y  electrical

X  Y electrical
